Ultra Electronics Card Systems

Rio Pro Maintenance Manual

- 107 -

Fig 1

Additional Plastic Flange now fitted to all

Rio Pro printers to prevent Rotation Belt

and Rotation Drive Belt slipping off.

Fitted to both pulleys on each side.
