IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-42
Table 5-4:V/f Parameters
Table 5-3:
Inverter
Voltage
E1-01
Setting
Overvoltage Trip Braking Transistor
Trip Reset On Off
230 150-255 400V 380V 380V 375V
460 400 800V 760V 760V 750V
460 <400 720V 680V 660V 650V
Parameter
Code Name Function Range
Initial
Value
Access
Level
E01.03 V/f Selection Selection V/f Pattern 00–0F, FF 04* Basic/Adv
E01.04
(3)
Max Frequency Maximum Frequency 40.0–150.0 Hz ** Basic/Adv
E01.05
(2)
Max Voltage Maximum Voltage 0.0–510.0 V ** Basic/Adv
E01.06 Base Frequency Motor Base Frequency 0.0–150.0 Hz ** Basic/Adv
E01.07 Mid Frequency A Midpoint Output
Frequency A
0.0–150.0 Hz ** Basic/Adv
E01.08
(2)
Mid Voltage A Midpoint Frequency
Voltage A
0.0–510.0 V ** Basic/Adv
E01.09 Min Frequency Minimum Frequency 0.0–150.0 Hz ** Basic/Adv
E01.10
(2)
Min Voltage Minimum Voltage 0.0–510.0 V ** Basic/Adv
E01.11 Mid Frequency B Midpoint Output
Frequency B
0.0–150.0 Hz ** Basic/Adv
E01.12
(2)
Mid Voltage B Midpoint Output
Voltage B
0.0–510.0 V ** Basic/Adv
E01.13
(2)
Base Voltage Motor Base Voltage 0.0–510.0 V **
***
Basic/Adv
* Initial value determined by X-Press Programming
** Initial value determined by voltage class and setting of E01.03. See Tables 5-5 and 5-6.
*** This value is automatically set during Auto-Tuning.
(1)
The initial value displayed here is for 460V class drives.
(2)
For 230V class units, the value is half that of 460V class units.
(3)
To change E01.04 “Max Frequency,” E01.03 must first be set to “0F”, or pick a V/f pattern from
Table 5-4 or 5-5.
