Table 5-5: Voltage/Frequency Pattern Options for 230 V Class
Table 5-6: Voltage/Frequency Pattern Options for 460 V Class
E01.04 E01.05 E01.06 E01.07 E01.08 E01.09 E01.10 E01.11 E01.12 E01.13
E01.03 Hz V Hz Hz V Hz V Hz V V
00
(4)
60.0 230.0 60.0 3.0 15.0 1.3 8.1 0.0 0.0 0.0
01 60.0 230.0 60.0 3.0 16.1 1.3 9.2 0.0 0.0 0.0
02 60.0 230.0 60.0 3.0 17.3 1.3 10.4 0.0 0.0 0.0
03 60.0 230.0 60.0 3.0 18.4 1.3 11.5 0.0 0.0 0.0
04
(5)
60.0 230.0 60.0 3.0 19.6 1.3 12.7 0.0 0.0 0.0
05 60.0 230.0 60.0 3.0 20.7 1.3 13.8 0.0 0.0 0.0
06 60.0 230.0 60.0 3.0 21.9 1.3 15.0 0.0 0.0 0.0
07 60.0 230.0 60.0 3.0 23.0 1.3 16.1 0.0 0.0 0.0
08 60.0 230.0 60.0 3.0 24.2 1.3 17.3 0.0 0.0 0.0
09 72.0 230.0 60.0 3.0 16.1 1.3 9.2 0.0 0.0 0.0
0A 72.0 230.0 60.0 3.0 17.8 1.3 10.9 0.0 0.0 0.0
0B 72.0 230.0 60.0 3.0 19.6 1.3 12.7 0.0 0.0 0.0
0C 90.0 230.0 60.0 3.0 16.1 1.3 9.2 0.0 0.0 0.0
0D 90.0 230.0 60.0 3.0 17.8 1.3 10.9 0.0 0.0 0.0
0E 90.0 230.0 60.0 3.0 19.6 1.3 12.7 0.0 0.0 0.0
0F (V/f) 60.0 230.0 60.0 3.0 19.6 1.3 12.7 0.0 0.0 0.0
0F
(OLV)
60.0 230.0 60.0 3.0 13.8 0.5 2.9 0.0 0.0 0.0
E01.04 E01.05 E01.06 E01.07 E01.08 E01.09 E01.10 E01.11 E01.12 E01.13
E01.03 Hz V Hz Hz V Hz V Hz V V
00
(4)
60.0 460.0 60.0 3.0 29.9 1.3 16.1 0.0 0.0 0.0
01 60.0 460.0 60.0 3.0 32.2 1.3 18.4 0.0 0.0 0.0
02 60.0 460.0 60.0 3.0 34.5 1.3 20.7 0.0 0.0 0.0
03 60.0 460.0 60.0 3.0 36.8 1.3 23.0 0.0 0.0 0.0
04
(5)
60.0 460.0 60.0 3.0 39.1 1.3 25.3 0.0 0.0 0.0
05 60.0 460.0 60.0 3.0 41.4 1.3 27.6 0.0 0.0 0.0
06 60.0 460.0 60.0 3.0 43.7 1.3 29.9 0.0 0.0 0.0
07 60.0 460.0 60.0 3.0 46.0 1.3 32.2 0.0 0.0 0.0
08 60.0 460.0 60.0 3.0 48.3 1.3 34.5 0.0 0.0 0.0
09 72.0 460.0 60.0 3.0 32.2 1.3 18.4 0.0 0.0 0.0
0A 72.0 460.0 60.0 3.0 35.6 1.3 21.8 0.0 0.0 0.0
0B 72.0 460.0 60.0 3.0 39.1 1.3 25.3 0.0 0.0 0.0
0C 90.0 460.0 60.0 3.0 32.2 1.3 18.4 0.0 0.0 0.0
0D 90.0 460.0 60.0 3.0 35.6 1.3 21.8 0.0 0.0 0.0
0E 90.0 460.0 60.0 3.0 39.1 1.3 25.3 0.0 0.0 0.0
0F (V/f) 60.0 460.0 60.0 3.0 39.1 1.3 25.3 0.0 0.0 0.0
0F
(OLV)
60.0 460.0 60.0 3.0 27.6 0.5 5.8 0.0 0.0 0.0
(4)
Default for Traverse Motion (A01.03 = 00) and Braketronic (A01.03 = 04)
(5)
Default for Hoist Motion (A01.03 = 01)
