IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-47
09 Lower Limit 2 N.O. Lower Limit - STOP; Normally
Open. LL2 - blinking
5-20 Basic/Adv
0A Upper Limit 1 N.C. Upper Limit - SLOW DOWN;
Normally Closed. UL1 -
blinking
5-20 Basic/Adv
0B Upper Limit 2 N.C. Upper Limit - STOP; Normally
Closed. UL2 - blinking
5-20 Basic/Adv
0C Lower Limit 1 N.C. Lower Limit - SLOW DOWN;
Normally Closed. LL1 -
blinking
5-20 Basic/Adv
0D Lower Limit 2 N.C. Lower Limit - STOP; Normally
Closed. LL2 - blinking
5-20 Basic/Adv
0E M-Speed Gain 1 Micro-Speed positioning
control multiplier 1. Gain is set
by parameter C02.01 (has
priority over MS2)
5-19 Adv
0F Not used No function - terminal is
disabled
-- Basic/Adv
10 M-Speed Gain 2 Micro-Speed positioning
control multiplier 2. Gain is set
by parameter C02.02.
5-19 Adv
12 Weight Limit N.C. Weighted Upper Limit (UL3);
Stopping Method determined by
C03.08.
5-20 Adv
13 Swift-Lift Swift-Lift Enable (C06.01 = 2).
Not available for Traverse
Motion
5-26 Basic/Adv
14 Alt T-Lim Gain Alternate Torque Limit Gain -
C07.05. Use when load testing
a hoist
5-30 Adv
15 Forward Jog Uses B01.17 reference 5-3 Adv
16 Reverse Jog Uses B01.17 reference 5-3 Adv
17 Forward Inch Inch Control 5-34 Adv
18 Reverse Inch Inch Control 5-34 Adv
19 Inch Repeat Inch Control 5-34 Adv
1A Acc/Dec 2 Acceleration and Deceleration
Time Changeover 2 using
B05.03 and B05.04
5-15 Basic/Adv
1B Acc/Dec 3 Acceleration and Deceleration
Time Changeover 3 using
B05.12 and B05.13
5-15 Adv
1C Acc/Dec 4 Acceleration and Deceleration
Time Changeover 4 using
B05.14 and B05.15
5-15 Adv
1D Digital Chngover Analog/Digital Reference
Changeover B01.18 = 1
Open = Analog
Closed = Digital
5-3 Adv
1F Opt/Inv Switch Option/Inverter Selection
(Frequency and Run Reference
from Option card. Closed =
Option Card). Set B03.01,
B03.02 = Terminals; set
H01.0X = 1F
5-6 Adv
Parameter
Code Name Function
Reference
Page
Number Range
Initial
Value
Access
Level
* = Parameter defaults changed by X-Press Programming
To Next Page
