Magnetek 2001-G+M - Page 108

IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
5-48
20 thru 2F External Fault Desired setting is possible.
Input mode: N.O./N.C.,
Detection mode: Always/
During Run (See external fault
response selection table 5-7)
5-53 Basic/Adv
30 Program Lockout Program Lockout
Closed: Parameters enabled to
write
Open: Parameters disabled to
write other than freq. reference
(U01.01)
-- Adv
31 Local/Remote Sw Closed = Local -- Adv
32 Ext BB N.O. N.O.: Baseblock by ON.
Immediate stop at STOP
command; normally open
-- Basic/Adv
33 Ext BB N.C. N.C.: Baseblock by OFF.
Immediate stop at STOP
command; normally closed
-- Basic/Adv
39 External OH2 Inverter overheat prediction
(OH2 is shown by ON). Alarm
only.
-- Adv
3A Trm A1/A2 Enable Multi-function analog input A1/
A2 Enable/Disable. When
programmed, analog input A1/
A2 is enabled by ON.
-- Basic/Adv
3F Fault Reset Reset by ON -- Basic/Adv
40 Fast Stop N.O. Deceleration to stop by fast
stop time B05.08 at ON
5-47 Adv
42 Fast Stop N.C. Deceleration to stop by fast
stop time B05.08 at OFF
5-47 Adv
43 Timer Enable Function settings by C12.03,
C12.04. It is set with timer
function output [Multi-
Function Output]
5-32 Adv
47 Analog Hold Analog frequency reference
Sample/Hold
-- Adv
4C DCInj Braking ON: DC injection braking
command, once SFS reaches
Zero Speed
-- Adv
53 Comm Test Communication test mode -
loopback test of modbus
RS-422/485 interface
-- Adv
55 Drive Enable When programmed, must be
ON in order for Inverter Ready
- Generates “Drive not
Ready”. “DNE” is displayed.
-- Adv
56 Klixon N.O. When Closed, Reset run
command, use stopping method
B03.03, display oL8 - Klixon
Alarm on Keypad
5-21 Adv
57 Klixon N.C. When Open, Reset run
command, use stopping method
B03.03, display oL8- Klixon
Alarm on Keypad
5-21 Adv
58 Brake Answer back Generates BE0, BE4, BE5,
alarm or fault conditions only
when programmed to MFI
(C08.04, C08.11)
5-31 Adv
Parameter
Code Name Function
Reference
Page
Number Range
Initial
Value
Access
Level
* = Parameter defaults changed by X-Press Programming
