IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
A-3
IMPULSE•G+ Mini Parameter Listing
Parameter Parameter Name Default Range Units
Reference
Page
A01.01 Access Level
0000: User
0001: Basic
0002: Advanced
0001 0000~0001 -- 4-13
A01.02 Control Method
00: V/f
02: OLV
00 00, 02 -- 4-13
A01.03 Motion
00: Traverse
01: Hoist
04: Braketronics
01 00, 01, 04 -- 4-14
A01.04 Speed Reference
00: 2-Speed Multi-Step
01: 3-Speed Multi-Step
02: 5-Speed Multi-Step
03: 2-Step Infinitely Variable
04: 3-Step Infinitely Variable
05: Analog - Uni-Polar
01 00–05 -- 4-14
A01.05 Initialize
0000: No Initialize
1110: User Initialize
5550: Moves modified parameters from
terminal board to control board
0000 0000–5550 -- 4-18
A01.06 Password 1 0000 0000–9999 -- 4-18
A01.08 Password 2 0000 0000–9999 -- 4-19
B01.01 Frequency Reference 1 15.00* 0.00–150.00 Hz 5-3
B01.02 Frequency Reference 2 30.00* 0.00–150.00 Hz 5-3
B01.03 Frequency Reference 3 60.00* 0.00–150.00 Hz 5-3
B01.04 Frequency Reference 4 0.00* 0.00–150.00 Hz 5-3
B01.05 Frequency Reference 5 0.00* 0.00–150.00 Hz 5-3
B01.06 Frequency Reference 6 0.00* 0.00–150.00 Hz 5-3
B01.07 Frequency Reference 7 0.00* 0.00–150.00 Hz 5-3
B01.08 Frequency Reference 8 0.00* 0.00–150.00 Hz 5-3
B01.09 Frequency Reference 9 0.00* 0.00–150.00 Hz 5-3
B01.10 Frequency Reference 10 0.00* 0.00–150.00 Hz 5-3
B01.11 Frequency Reference 11 0.00* 0.00–150.00 Hz 5-3
B01.12 Frequency Reference 12 0.00* 0.00~150.00 Hz 5-3
B01.13 Frequency Reference 13 0.00* 0.00–150.00 Hz 5-3
B01.14 Frequency Reference 14 0.00* 0.00–150.00 Hz 5-3
B01.15 Frequency Reference 15 0.00* 0.00–150.00 Hz 5-3
B01.16 Frequency Reference 16 0.00* 0.00–150.00 Hz 5-3
B01.17 Jog Reference 6.00* 0.00–150.00 Hz 5-3
* Parameters defaults changed by X-Press Programming
** Parameters changed by E01.03
*** Value depends on drive model
**** Default value depends on control method
