IMPULSE•G+ Mini Advanced Instruction Manual – March 2014
4-8
Use the following table to select the desired motor for your application:
Use the , , and keys to change the value.
Press to save your changes. The display will temporarily show , then A01.03.
Setting Speed Reference:
Press the key to navigate to A01.04 (Speed Reference), press .
Use the following table to select the speed reference for your application:
Use the , , and keys to change the value.
Press to save your changes. The display will temporarily show , then A01.04
A01.03 - Motion
Data Value Function
00 Traverse
01 Hoist (Default)
A01.04 - Speed Reference
Data Value Function
00 2-speed Multi-Step
01 3-speed Multi-Step (Default)
02 5-speed Multi-Step
03 2-step Infinitely Variable
04 3-step Infinitely Variable
05 Uni-Polar Analog (0-10 VDC or 4-20mA)
