Manitowoc Grove RT9150E User Manual

3-59
RT9150E OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
Published 2-23-2017, Control # 644-00
Grove
Operating Hours
Press the Settings submenu button in the Main menu and
then press the Operating hours button (1) (Figure 3-55) to
open the Operating Hours submenu.
Operating Hours Submenu
The operating hours are displayed below the symbols, e.g.
1,680 hours and 12 minutes for the telescoping mechanism
(3).
NOTE: The value below the Unlock telescopic section
symbol (6) (Figure 3-56) indicates how often the
cycle has been operated, e.g. 13,750 times.
FIGURE 3-55
1
FIGURE 3-56
Item Description
1ECOS
2
Auxiliary systems:
Counterweight cylinders
Crane cab cylinder
3 Telescoping mechanism
4 Engine operation
5 Lift cylinder
6 Telescope locking system
7 Main hoist
8 Auxiliary hoist
9 Swing gear
10 Boom extension
Reference Only
