5-27
RT9150E OPERATOR MANUAL LUBRICATION
Published 2-23-2017, Control # 644-00
Item
Lube Point
Description
Figure No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Boom
130
Telescope
Sections -
Lower Faces
Figure 5-11
Lubricant Grease
02310394
Thoroughly
coat
300 hours or 3 months
5 places by brush.
Refer to Boom
Lubrication Procedure.
131
Telescope
Sections -
Upper Faces
Figure 5-11
Lubricant Grease
02310394
Thoroughly
coat
300 hours or 3 months
10 places by brush.
Refer to Boom
Lubrication Procedure.
Boom Lubrication Procedure
Telescope Section 1
• Extend telescope section 1 to 100%.
• Using a brush or roller, apply grease to lower slide faces.
• Apply grease to the upper wear pads at fitting (item 131).
• Lubricate locking pins at fitting (item 132).
• Lock and unlock the section to distribute the grease.
• Extend section 1 to 50%
• Apply grease to the upper wear pads at fitting (item 131).
Fully retract section.
Telescope Section 2 - 5
• Extend telescope section 5 to 100% and telescope section 4 to approximately 25%.
• Using a brush or roller, apply grease to the lower slide faces.
• Apply grease to the upper wear pads at fitting (item 131).
• Lubricate locking pins at fitting (item 132).
• Raise the main boom to 15 degrees.
• Retract telescope section 4 to 0% and telescope section 5 to approximately 50%.
• Lock and unlock telescope section 5 several times to distribute the grease.
• Lower the main boom to 0 degrees. Do not lower less than 0 degrees.
• Extend telescope section 4 to approximately 75%.
• Apply grease to the upper wear pads at fitting (item 131)
• Raise the main boom to 15 degrees.
• Retract telescope sections 4 and 5 to 0%,
• Fully extend and retract telescope section 5 to distribute the grease.
• Lower the main boom to 0 degrees.
• Lubricate telescope sections 2, 3 and 4 in the same method.
