OPERATING CONTROLS AND PROCEDURES RT9150E OPERATOR MANUAL
3-52
Published 2-23-2017, Control # 644-00
SETTINGS SUBMENU
Press the settings submenu button (Figure 3-47) in the main
menu to open this submenu.
Settings Submenu
Refer to the following table for a description of each item
listed above.
FIGURE 3-47
FIGURE 3-48
1
2
3
4
5
6
7
9
11
10
8
Item Description
1 Outrigger control graphic
2 Setting control lever characteristics
3 Setting the display brightness
4 Telescoping emergency program access
5 Lamp test
6 Operating hours submenu
7 Critical load control, on/off
8 Current telescoping mechanism status display
9 Telescoping cylinder hydraulic pressure
10 Swing gear hydraulic pressure
11 Hydraulic circuit pressure
Item Description Graphic Explanation
1
Outrigger control
graphic
No function.
Reference Only
