Manitowoc Grove RT9150E - LIFT CYLINDER LUBRICATION

To Next Page

To Previous Page

5-23

RT9150E OPERATOR MANUAL LUBRICATION

Published 2-23-2017, Control # 644-00

Grove

Item

Lube Point

Description

Figure

No.

Approved

Lubricant

Lube

Capacity

Lube Interval Application

Lift Cylinder

116

Lower Lift

Cylinder Pivot

Figure 5-9

EP-MPG

Extreme

Pressure

Multipurpose

Grease

6829003477

6829104275

Until

grease

extrudes

100 hours or1 months 1 grease fittings
