3-71
RT9150E OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
Published 2-23-2017, Control # 644-00
10 Entering values
When Input mode is activated:
• To the right: increases the value
• To the left: reduces the value
Slow turning changes the value slowly.
Fast turning changes the value fast.
11 RCL shutdown
• On: Machine Shutdown, buzzer
sounds
Degree of utilisation about 100% or
an error exists.
• Off: No shutdown
Refer to RCL Shutdown, page 3-72.
12 Input confirmation
The lamp (1) lights up.
In the Rigging mode submenu:
Press button once, rigging mode
monitoring submenu opens.
In the Rigging mode monitoring
submenu:
Press button once, rigging mode is
accepted, Monitoring submenu
opens, lamp (1) goes out.
1
Either Item 2 or 5
Item Description Graphic Explanation
Reference Only
To Next Page
