Manitowoc Grove RT9150E - Page 245

4-11
RT9150E OPERATOR MANUAL SET-UP AND INSTALLATION
4
Grove
Published 2-23-2017, Control # 644-00
Six Parts Line - 3.6 Meter Extension
Fold-Down Sheave Assembly
Use Wedge Socket Adapter Kit
Fold-Up Deflection Sheave
FIGURE 4-12 continued
Reference Only
