Chapter 10: MOC-9
Flexible measurement expansion is enabled through MOC-9. It can display parameters and
measurements captured by SedLine, ISA Capnography, and third-party technologies in an
all-in-one view on Root.
When any MOC-9 module is connected, Root automatically creates a Window that displays all
the data from that module. The example below shows the “SedLine” and “Capnography”
Windows which display data from the SedLine brain function monitoring and ISA
capnography MOC-9 modules that are connected to Root.
Using MOC-9 Ports
Use a MOC-9 cable to connect other MOC-9 modules to Root.
To use an MOC-9 Port
1. Identify the MOC-9 end of the cable.
2. Orient the cable to fit correctly into an MOC-9 Port.
3. Insert the MOC-9 cable securely into any of the three (3) compatible ports on
Root.
