Masimo Root User Manual

Root NIBPT Chapter 15: Specifications
www.masimo.com 137 Masimo
Root
Storage Humidity 10% to 95%, non-condensing
Operating Air Pressure
500 mbar to 1060 mbar
-1000 ft to 18,000 ft
(-304 m to 5,486 m)
Touchscreen Display
Characteristic Description
Type Backlit Active Matrix TFT LCD
Resolution 1280 x 800 pixels
Size 10.1 in (25.65 cm) Diagonal
Color 24 bit RGB
Touchscreen Type Multi-Touch P-Cap
Wireless Specifications
Communication (Wi-Fi)
Type WLAN Radio: IEEE 802.11 a/b/g
Frequency
802.11a: 5180-5240 MHz, 5745-5825 MHz
802.11b/g: 2412-2462 MHz
Max Peak Output Power WLAN 17 dBm
Classification of Output Power Rating Conducted
Output Power Type Fixed at the Factory
Modulation Types OFDM, BPSK, CCK

Masimo Root Specifications

General

Category	Medical Equipment
Display	10.1 inch touchscreen
Connectivity	WiFi, Bluetooth
Power Supply	AC power
Dimensions	26.8 cm x 22.4 cm x 5.1 cm
Ports	USB, Ethernet
Supported Parameters	SpO2, Pulse Rate
Compatibility	Masimo sensors
Model	Root
