Masimo Root User Manual

Root NIBPT Chapter 15: Specifications
www.masimo.com 134 Masimo
Alarms
Audio Alarm
Type
System Status
Light Color
Audio Description
High Priority Flashing Red 10-pulse burst, pulse spacing: 0.250s, 0.250s,
0.500s, 0.250s, repeat time:10s
Medium
Priority
Flashing Yellow 3-pulse burst, pulse spacing: 0.375s, 0.375s, repeat
time: 7s
Low Priority Solid Yellow No audio
Nurse Call Specifications
The Nurse Call relays have the following electrical specifications per switch:
Parameter Specification
Max Voltage 36 VDC or 24 VAC peak
Connectors
Connector Type Number of Ports
Ethernet 10/100 Mbps 1
Nurse Call 1/4 inch round female 1
MOC-9 Masimo Connector 3
USB USB 2.0 2
Iris RS-232/RJ-45 4
NIBP Nib Male Bayonet 1
Temperature MOLEX 52271-0690 1

Masimo Root Specifications

General

Category	Medical Equipment
Display	10.1 inch touchscreen
Connectivity	WiFi, Bluetooth
Power Supply	AC power
Dimensions	26.8 cm x 22.4 cm x 5.1 cm
Ports	USB, Ethernet
Supported Parameters	SpO2, Pulse Rate
Compatibility	Masimo sensors
Model	Root
