Root NIBPT Chapter 3: Operation
www.masimo.com 37 Masimo
Using the Touchscreen Interface
Use the gestures described below to customize the viewing experience, including displaying
the highest priority parameters and measurements. The availability of navigation features is
dependent on the connected medical devices.
Action Illustration Example Description
Press
Press and release. Action performed
once finger is released.
Slide
Press, move (left, right, up or down),
and release. Moves an object across
the display.
Swipe
Press, move (left, right, up or down),
and release quickly.
Pinch
Press, move, and release two points.
Moving points apart zooms in, and
moving them together zooms out.
Drag
and
Drop
See Customizing Windows on
page 46.
Press, hold, drag an object to
desired position, and drop it by
releasing.
Below is a list of all the different types of controls available on Root and the various ways to
interact with each type of control.
Control Applicable Actions Description
Toggle Slide knob Switches between toggle states
Press left or right of
toggle
Quickly moves knob left or right
