Masimo Root User Manual

Root NIBPT Chapter 3: Operation
www.masimo.com 46 Masimo
Customizing Windows
Windows can be customized by expanding and minimizing parameters and measurements in
both Trend View and Analog View. When a parameter is minimized, it is only displayed in the
Well with its Numeric Value and Parameter Label. When a parameter is expanded, it will be
shown as either a Trend Display or Gauge.
To expand a parameter or measurement
Order Instruction
Step 1 Press and hold the Numeric Value until it dims.
Step 2 Drag the Numeric Value over any Trend Display.
Step 3 Release the Numeric Value.

Masimo Root Specifications

General

Category	Medical Equipment
Display	10.1 inch touchscreen
Connectivity	WiFi, Bluetooth
Power Supply	AC power
Dimensions	26.8 cm x 22.4 cm x 5.1 cm
Ports	USB, Ethernet
Supported Parameters	SpO2, Pulse Rate
Compatibility	Masimo sensors
Model	Root
