Chapter 3: Operation
The information in this chapter assumes that Root is set up and ready for use. This chapter
provides necessary information for proper operation of the device. Do not operate Root
without completely reading and understanding these instructions.
About the Main Screen
The Main Screen consists of several features. The following shows the Main Screen when two
different devices are connected: Radical-7 (top) showing rainbow
®
parameters and
measurements, SedLine
module (middle) showing brain function measurements.

Masimo Root Specifications

General

Category	Medical Equipment
Display	10.1 inch touchscreen
Connectivity	WiFi, Bluetooth
Power Supply	AC power
Dimensions	26.8 cm x 22.4 cm x 5.1 cm
Ports	USB, Ethernet
Supported Parameters	SpO2, Pulse Rate
Compatibility	Masimo sensors
Model	Root
