Masimo Root User Manual

Root NIBPT Chapter 11: Iris
www.masimo.com 118 Masimo
Ref. Description
4 Patient SafetyNet or Masimo Connectivity Gateway
5 Notification devices
6
Electronic Health Records system
Using Iris Connectivity Ports
Use Iris Adapters and RJ-45 cables to connect standalone devices to Root.
To connect a standalone device via an Iris Connectivity Port:
1. Connect the Iris Adapter to the standalone device. Refer to the Iris Adapter
Directions for Use.
2. Connect the RJ-45 end of the Iris Adapter to any of the four (4) compatible Iris
Connectivity Ports on Root using a RJ-45 cable.

Masimo Root Specifications

General

Category	Medical Equipment
Display	10.1 inch touchscreen
Connectivity	WiFi, Bluetooth
Power Supply	AC power
Dimensions	26.8 cm x 22.4 cm x 5.1 cm
Ports	USB, Ethernet
Supported Parameters	SpO2, Pulse Rate
Compatibility	Masimo sensors
Model	Root
