Chapter 13: Messages
The following messages are specific to Root:
Message Explanation Next Step
Battery Charge is
Low.
The internal battery needs to be
charged. System Status Lights
flash yellow.
Charge Root's battery using AC power.
MOC-9 module
Disconnected
(e.g. SedLine
Disconnected)
A MOC-9 module is disconnected
from Root.
Reconnect module or acknowledge
message by pressing the Alarm
Silence icon.
Radical-7
Disconnected
Radical-7 is disconnected from
Root.
Reconnect Radical-7 or acknowledge
message by pressing the Alarm
Silence icon.
Radius-7
Disconnected
Radius-7 is disconnected from
Root.
Reconnect Radius-7 or acknowledge
message by pressing the Alarm
Silence icon.
Check Probe Probe is not responsive.
Check probe tip condition. Re-insert
probe into probe well or check for
alignment problem. If problem
persists, replace the probe. If problem
still persists, contact Customer
Service.
Retake
Measurement
An error has occurred in the
process of taking a patient
temperature measurement
with the optional integrated
temperature module.
Try another measurement cycle. If
problem persists, replace probe.
Check Ambient
Temperature
Ambient temperature may be
too high or too low.
Verify ambient temperature does not
exceed operating specification.
Check internal temperature at probe
well.
Replace Probe
Probe is not responsive due to
not being calibrated or
damaged.
Replace probe.
