Masimo Root User Manual

Root NIBPT Chapter 1: Description
www.masimo.com 24 Masimo
Side Views
Left Side Right Side
Ref. Feature Description
1 System Status Lights
Provides an indication of system messages and
alarm priority. See System Status Lights on page
86.
2 Power Button
Places Root in Power On, Sleep, and Power Off
modes.
3 MOC-9 Ports (3) Provide connectivity for MOC-9 modules.
4 NIBP Nib Connection port for NIBP Hose.
5 Temperature Probe Port* Allows connection of temperature probe to Root.
6 Temperature Probe Well Holder*
Provides dock for temperature probe when not
measuring.
7 Probe Covers Holder Holds extra probe covers for quick access.
*This feature is optional on Root

Masimo Root Specifications

General

Category	Medical Equipment
Display	10.1 inch touchscreen
Connectivity	WiFi, Bluetooth
Power Supply	AC power
Dimensions	26.8 cm x 22.4 cm x 5.1 cm
Ports	USB, Ethernet
Supported Parameters	SpO2, Pulse Rate
Compatibility	Masimo sensors
Model	Root
