Root NIBPT Chapter 3: Operation
www.masimo.com 87 Masimo
Root Charging Indicator
Whenever Root is connected to an AC power source, if not fully charged, its battery will
charge.
Light Status Battery Indication
Green Battery is fully charged.
Orange Battery is charging.
Red Battery charging error.
Off Battery is not being charged. Root is not connected to AC power source.
Radical-7 and Radius-7 Charging Indicator
When Root is connected to an AC power source, it is able to charge a correctly docked
Radical-7 or Radius-7. This is true whether the device is powered on, in Sleep Mode, or
powered off. Conversely, when Root is not connected to AC power, it will not charge the
device.
The light status provides a visual indication of the battery condition:
Light Status Battery Indication
Green Battery is fully charged.
Orange Battery is charging.
Red Battery is unable to charge.
Off Battery is fully charged, not being charged.
