5.5.3. Quick repairs for rear steering
If the rear wheels remain turned and control panel input has no effect, disconnect the two solenoid heads
① and straighten the wheels by pushing the solenoid valve pushers with a rod.
During this operation, the operator will be on the side of the machine, and therefore near to the wheels.
This operation requires extensive caution. Before starting the operation, anticipate the direction of the
future movement of the wheels and work from the safest point.
Push to the right or
left of the rod
