XV. Deutz Liquid Crystal Display
15.1. General description
TheDeutzdisplayallowstheusertodisplaythevariousengineparameters.
TheDeutzdisplayisaliquidcrystaldevicewith5buttonsonthebase,usedtoselectthedifferentdisplaymodes
available.
Agraphicmenuassociatedwiththesebuttonsensureseasyuse.Userscandisplaytherequiredinformationin
variousformats.
 Analogue
 Digital
 Graphic
 Multi-purpose
 Alarmmessages
