User notice
M24D Hellios
V 1.0
Pictograms
Pictograms are included throughout this manual to bring the attention of the reader to specific points. Pictograms
and meanings are listed below.
This symbol will be used for all safety notices, where non-compliance would lead to
a direct risk for the health or mortality of the people concerned. Strict compliance is
necessary. Pass these safety instructions on to operators.
This symbol indicates a risk for the machine in the event of incorrect use or handling (risk
of irrevocable mechanical damage). Please comply with the instructions in this manual.
Important information.
This symbol does not indicate a danger, but brings the operator's attention to important
information or a specific setting required for optimum use of the machine.
Symbol indicating that additional information can be found in the DEUTZ instruction
manual.
Symbol indicating that additional information can be found in the M24D Hellios
maintenance log.
Maintenance symbol.
Information on maintenance intervals and references for consumables is indicated where
appropriate.
This symbol indicates that some maintenance operations must be carried out by a
MATROT technician or other member of personnel, or can be carried out by the user,
possibly with the agreement of MATROT Équipements.
Symbol referring to the necessary precautions for the recovery and recycling of bright oils
(e.g. hydraulic oil).
Symbol referring to the necessary precautions for the recovery and recycling of black oils
(mainly engine oil).
