66 2011

User notice

M24D Hellios

V 1.0

6.8. Relays and Fuses

◦Protection devices (fuses, see photo above)

Fuses are located behind the arm rest. Move the seat forward and fold the back down for easier handling.

Fuses

Relays

Relays and fuses
