80 2011
User notice
M24D Hellios
V 1.0
43
44
45
53
46
52
49
50
48
51
47
10.2. Direct lling (Liquid fertiliser) - Position 3B
1. Program the quantity and density required in the tank using the
860 control panel ㊸
2. Set the tank bottom valve to the mixing position ㊹
3. Release the mechanical gauge of the main tank ㊺
4. Open the lid of the main tank ㊻
5. Remove the cap from the symmetrical half union on the intake
6. Connect the suction pipe
7. Rotate the valves to position 3 B ㊼
8. With the combustion engine at idle
9. Engage the pump ㊽
10. Gradually accelerate the engine to mid-power ㊾
When the quantity required for filling is reached:
12. The pump will stop automatically
13. Reduce engine power ㊿
14. Rotate the valves to position 1 A (Spray)
15. Close the lid of the main tank
16. Retract the mechanical gauge of the main tank
17. Disconnect the suction pipe
18. Fit the cap on the symmetrical half union
