5.6.2. Retracting the booms
◦ Ensure that the self-propelled machine is on the flat and stopped (zero speed and joystick at neutral)
and that the engine is running at 1 500 rpm.
◦ Set switch ① to ON the indicator will light up.
◦ Check that the extended boom is horizontal.
◦ Push ③ to the right to lock the entire boom in position.
◦ Push ⑥ to the left to retract the outer right arm.
◦ Push ⑧ to the right to retract the outer left arm.
◦
Push
④
to the left or press
⑫
to activate the right boom and raise to maximum.
◦
Push
②
to the right or press
⑪
to activate the left boom and raise to maximum.
◦ Push ⑤ upwards or press ⑯ to raise the entire boom assembly.
◦ Block the boom in position by rotating ⑲ anti-clockwise.
◦ Keep your finger on ⑮ for 4 to 5 seconds to expand the nitrogen balls.
◦ Push ⑦ to the left to retract the main arms.
◦ Push ④ to the right or press ⑬ to place the right boom on its support bracket.
◦ Push ② to the left or press ⑭ to place the left boom on its support bracket.
◦ Keep your finger on ⑬⑭ for 4 to 5 seconds to well expand the nitrogen balls..
◦ Set switch ① to OFF, the indicator will go out.
◦ The boom is in the Road configuration.
REMINDER:
The booms must be extended and retracted with the engine running at 1 500 rpm.
Only use one switch at once to control boom manoeuvers.
Do not forget to expand the nitrogen balls to avoid the booms jumping on the support
plates with irregularities on the road and damage to the boom arms and support
brackets.
