56 2011
User notice
M24D Hellios
V 1.0
6.5. Motor
For more information, refer to the DEUTZ instruction manual 2012 supplied at the delivery of the
self-propelled machine.
6.5.1. Recommended lubrication
Refer to the DEUTZ instruction manual 2012, paragraph 4.
The engine oil used to fill the engine casing is API "CD/SF" TOTAL RUBIA SAE 30 grade oil
suitable for the running-in period.
6.5.2. Drainage period
1
st
drainage after 50 operating hours
2
nd
drainage after 200 operating hours
And then every subsequent 200 hours
Refer to the M24D Hellios maintenance log
Do not spill waste oil on the ground. Eliminate the oil in accordance with legislation on the protection
of the environment !
(directive no. 87/101/CEE)
CHECK THE OIL LEVEL EVERY MORNING
Filling orifice
Drainage
Oil level
