Matrot M24D Hellios - 6.6. Type of oil and capacity

60 2011
User notice
M24D Hellios
V 1.0
6.6. Type of oil and capacity
6.6.1. Motor
1
st
drainage after 50 operating hours
2
nd
drainage after 200 operating hours
And then every subsequent 200 hours
COMPONENTS
TYPE
(TOTAL brand)
CAPACITY
in litres
Combustion engine TCD 2012 L04 2V
See specifications below
TOTAL RUBIA TIR 8600
12.5 litres without the filter
14.0 litres with the filter
Engine
series
DEUTZ quality class
Lubrication oil quality
DQC I-02 DQC II-05 DQC III-05 DQC IV-05
Greasing intervals in operating hours
TCD 2012 2V - 200 200 200
DEUTZ recommendations
Refer to the DEUTZ instruction manual 2012, paragraph 4.
DEUTZ lubrication oil quality class DQC I-02 DQC II-05 DQC III-05 DQC IV-05
DEUTZ oil DQC I-02 DQC II-05 DQC III-05 DQC IV-05
ACEA classication
E2-96
E7-04 or E3-96 or E5-02
or E4-07 or E6-04
- -
API classication
CF or CF-4
CG-4 or CH-4 or CI-4 or
CI-4 Plus or CJ-4’
- -
International specication - DHD-1 - -
6.6.2. Transmission components
COMPONENTS
TYPE
(TOTAL brand)
CAPACITY
in litres
Ground
clearance:
1.00 m
Track: 1.80 - 2.00 m
Transmission DA
13.0 litres
Track: 1.90 - 2.10 m 14.0 litres
Track: 2.25 - 2.40 m 18.0 litres
Ground
clearance:
1.30 m
Upper corner bracket
Transmission EP 80 W 90
2.3 litres
Lower corner bracket 1.3 litres
Track: 2.25 m
Transmission DA
16.0 litres
Track: 2.40 m 17.0 litres
Ground
clearance:
1.60 m
Upper corner bracket
Transmission EP 80 W 90
2.3 litres
Lower corner bracket 1.3 litres
Track: 2.25 m
Transmission DA
16.0 litres
Track: 2.40 m 17.0 litres
Final
reducer
25 km/h
Transmission EP 80 W 90
6.5 litres
40 km/h 6.5 litres
Transfer gearbox
25 km/h
Transmission EP 80 W 90
3.5 litres
40 km/h 3.0 litres
