6.9. Filtration
The filter is located under the roof behind the cab.
The activated carbon filter must be changed when saturated and every 400 hours or annually as a
minimum. Refer to the M24D Hellios maintenance log.
◦Unscrew the screw
③
and open the flap to reach the filter ④
Filter reference:
Reference
Paper / carbon filter 232 925 000
Cleanthecondenserperiodically(honeycomb)②.
