A levelling valve is associated with each tank (1 FRONT and 2 REAR)
is valve will maintain a constant suspension height irrespective of load (full tank/empty tank.)
e shock absorbers tted on each axle prevent rebound.
Rear suspension
Front suspension
Levelling valve
Bellows
Shock absorber
Bellows
Levelling valve
min. 140
mm
Shock absorber
min. 140
mm
