Chapter 6 Communication function
110
Details of the contents and fields of Message 860:
Message 860 applies to the probe latch related applications, message content as follows:
Message 860
P362=860
Receiving word (1 PZD) Sending word (9 PZD)
PZD1 TB_FUNCTION TB_STATUS
PZD2
TB1_POS_VALUE
PZD3
PZD4
TB1_NEG_VALUE
PZD5
PZD6
TB2_POS_VALUE
PZD7
PZD8
TB2_NEG_VALUE
PZD9
TB_FUNCTION: Touch Probe latch function setting, U16.
For details, see 6.4.1 Touch Probe Functions.
TB_STATUS: Touch Probe latch status, U16.
For details, see 6.4.1 Touch Probe Functions.
TB1_POS_VALUE: Touch Probe 1 Latch position value, U16.
TB1_NEG_VALUE: Touch Probe 1 latch position value, U16.
TB2_POS_VALUE: Touch Probe 2 latch position value, U16.
TB2_NEG_VALUE: latch position value of the falling edge of Touch Probe 2, U16.
For details, see 6.4.1 Touch Probe Functions.
