Maxsine EP3 E Series - DI Function Detail

Chapter 5 Parameters
90
5.5 DI function detail
See "6.5.3 Digital input/digital output" for details. The following table shows the function
description of IO.
Ordinal Symbol DI Function Functional explanation
0 NULL No function Input state had no effect on the system.
2 ARST Clear alarm
When there is an alarm, if the alarm allows clearing,
enter the rising edge (OFF changes ON moment) to
clear the alarm. Note that only part of the alarm is
allowed to clear.
3 CCWL
CCW drive
inhibition
OFF：CCW rotation is prohibited;
ON ：CCW rotation is allowed.
For mechanical limit travel protection, function
controlled by parameter P097. Note that the default
value of P097 is to ignore this function. If you want to
use this function, you need to modify P097.
P097 Explanation
0 Using the forward drive disable function,
the normally closed contacts of the travel
switch must be connected.
2
1 Ignore forward drive forbidden function,
motor can run in the positive direction,
this signal has no effect, no need to
access.
3
(default)
4 CWL
Reverse
drive ban
OFF：CW rotation is prohibited;
ON ：CW rotation is allowed.
For mechanical limit travel protection, function
controlled by parameter P097. Note that the default
value of P097 is to ignore this function. If you want to
use this function, you need to modify P097.
P097 explain
0 Using reverse driving ban function, must
answer the normally closed contact of
stroke switches.
1
2 Ignore forward drive forbidden function,
motor can run in the positive direction,
this signal has no effect, no need to
access.
3
(default)
