Chapter 1 Product inspection and installment
12
1.6
Motor rotation direction definition
The motor rotating direction description in this handbook is defined as facing the shaft of
the servomotor, if the rotating shaft is in counterclockwise direction will be called as positive
direction, or in clockwise as reversal direction
Positive Rotation
Counterclockwise (CCW)
Reversal Rotation
Clockwise(CW)
