Chapter 5 Parameters
76
cannot run in this direction when OFF.
Neglect: the motor can run in this direction, the driver forbid signal has no effect, can not
access the signal.
P098 Force enable
Range
Default
value
Unit Usage
0～1 0 ALL
 P098 parameter is invalid when P304 = 1, effective P304 = 0.
 Parameter meaning:
0: Enable by DI input SON control;
1: Software enablement.
5.4.2 Parameters of section 1
P100 Digital input DI1 function
Range
Default
value
Unit Usage
-37～37 4 ALL
 Input DI1 function planning by number. Absolute value of parameter represents function
and symbol represents logic. Please refer to Section 5.5 for function.
 Symbol denotes input logic, positive numbers denote positive logic, negative numbers
denote negative logic, ON is valid, OFF is invalid:
Parameter value DI input signal DI result
Positive number
Open circuit OFF
Conduction ON
Negative number
Open circuit ON
Conduction OFF
 When multiple input channels have the same function choice, the function result is
logical or relational. For example, P100 and P101 are both set to 1 (SON function), then
DI1, DI2 any ON, SON is valid.
 Input functions that are not selected by parameters P100 ~ P104, i.e. unplanned functions,
result in OFF (invalid). With exceptions, setting parameters P120 ~ P124 can force the
function ON (valid), whether the function is planned or not.
P101 Digital input DI2 function
Range
Default
value
Unit Usage
-37～37 3 ALL
 Digital input DI2 function planning, refer to parameter P100 description.
P102 Digital input DI3 function
Range
Default
value
Unit Usage
-37～37 23 ALL
 Digital input DI3 function planning, refer to parameter P100 description.
