BOLT TORQUE VALUES
IMPORTANT: Replace a damaged bolt with a bolt of the same strength value marked on its head.
Standard torques are used, except in the locations specied below:
Bolts For: Dimension Nm Torque (ft. lb.)
Securing Door Lock M5 2.5 1.8
Central Door Handle M6 8.8 6.5
Door Handle Turning Mechanism 3.5 - 3.8 2.6 - 2.8
Door Hinge, Front Panel M6 8.8 6.5
Anchoring M16 100 73 - 74
External Tub Tightening Flange M8 26 19 - 20
Motor Holder M12 5 3.7 - 4
