3-45
1. Remove the door support front plate.
(See page 3-44)
2. Pull the drip shield off which is installed with
double stick tape.
3. The three covers at the bottom are for
heater elements, which would have to be
removed if they were present.
4. Mark tub front cover, clamp and tub to assist
in proper orientation during reinstallation.
5. Measure from the base of the washer to the
middle of a bolt on the tub front cover. Mark
the distance on the cover.
6. Measure and mark a bolt on the other side
for proper orientation during reinstallation.
7. Loosen the 13mm nuts on both ends of top
bolt clamp securing the tub front cover.
8. Support the tub front cover.
9. Release the clamp and remove it from
around the edge of the cover.
10. Remove tub front cover from the washer.
11. There is a gasket around the entire edge
inside the cover.
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before
operating.
TUB FRONT COVER
Three
Covers
Gasket
To Next Page
