3-17
1. Open the top panel. (See page 3-1)
2. To remove the top panel prop rod, rotate the
rod forward.
3. Slide the end of the hook out of the
mounting hole.
4. The rubber grommet can be removed from
the prop rod mounting hole.
5. The top panel prop rod support is attached
to the chemical dispenser support with
double stick tape.
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before
operating.
TOP PANEL PROP ROD
Prop Rod
Support
Grommet In
Mounting Hole
To Next Page
