5-6
3. Motor test
4. Test of outputs for external chemical pumps
5. Water fill, heating and drain test
6. BASIC Diagnostic Wash program
DIAGNOSTIC PROGRAM
The purpose of the Diagnostic Program is to
test the washer functions one by one.
TEST SEQUENCE
1. Display test and door lock test
2. Sensor test
53
DIAGNOSTIC PROGRAM
The purpose of the Diagnostic Program is to test the washer
functions one by one.
n HOW TO GET INTO THE DIAGNOSTIC MENU
1. Select Cycle is displayed.
Enter the Setup Mode. (See page 5.)
The Main Menu is now available.
Press ARROW DOWN to select the Service Menu.
Select the Diagnostic Program Menu at the Service Menu.
• Select diagnostic program.
• Press START if you want to start the diagnostic program.
Diagnostic Prog …
Service Menu
Start Cycle No
Exit
Diagnostic Cycle
TEST SEQUENCE
Display test and door lock test
Sensor test
Motor test
Test of outputs for external liquid detergent pumps
Water fill, heating and drain test
BASIC Diagnostic Wash program
n Select Diagnostic Program
• Select diagnostic program.
• Press START if you want to start the diagnostic program.
Diagnostic Prog …
Service Menu
Start Cycle No
Exit
Diagnostic Cycle
n Press START if you want to start
Diagnostic Program.
NOTE: The second drain valve will be opened if the second drain valve has been selected in the Configuration Menu.
No number 2 is displayed at the sensor test as this takes only a fraction of a second.
REMARK: If ++ ++ is displayed at the motor test sequence, then you can Advance (press START) the test Sequence.
Test Info Explanation
1
Black display followed
by a Text display.
Door lock test (locks and unlocks the door 5 times)
Display test
*** None Sensor test (all washer sensors are tested)
3 Motor Reverse Wash Speed (inverse direction high spin)
4 Motor Stop Standstill motor
5 Motor Forward Wash Speed (same direction high spin)
6 Motor Distribute Distribution speed (same direction high spin)
7 Motor Low spin Low spin speed (same direction high spin)
8 Motor High spin High spin speed
9 Motor Stop Free run or controlled deceleration
15 Detergents 1..8 The external liquid detergent pumps get activated one by one
20 Inlet 1 The washer takes water at inlet 1
21 Drain 1 The water is drained at drain valve 1
22 Inlet 2
The washer takes water at inlet 2 until the safety level for heating is reached
Heating activated (only if Wait temp = on)
23 Drain 1 (2)* The water is drained at drain valve 1
24 Inlet 3 The washer takes water at inlet 3
25 Drain 1 The water is drained at drain valve 1
26 Inlet 4 The washer takes water at inlet 4
27 Drain 1 The water is drained at drain valve 1
28 Inlet 5 The washer takes water at inlet 5
29 Drain 1 The water is drained at drain valve 1
30 Inlet 6 The washer takes water at inlet 6
31 Drain 1 The water is drained at drain valve 1
32 Inlet 17 The washer takes water at inlet 7
33 Drain 1 The water is drained at drain valve 1
34 Inlet 18 The washer takes water at inlet 8
35 Drain 1 The water is drained at drain valve 1
50 Tumble The tumble sequence
Unload End of the Diagnostic Cycle
