1-12
TECHNICAL SPECIFICATIONS
Model (lb/kg) 20/9 25/11 30/14 40/18 55/24 65/28
Washer Dimensions (inches/mm)
Width 25.98/660 29.53/750 29.53/750 35.03/890 35.03/890 35.03/890
Depth 30.91/785 30.91/785 35.43/900 36.02/915 41.73/1060 44.68/1135
Height 43.89/1115 48.22/1225 48.22/1225 55.51/1410 55.51/1410 55.51/1410
Packaging Dimensions (inches/mm)
Width 27.25/690 30.75/780 30.75/780 36.25/920 36.25/920 36.25/920
Depth 32.50/825 32.50/825 37.00/940 37.75/960 44/25/1125 46.75/1185
Height 48.50/1230 52.50/1335 52.50/1335 60.50/1535 60.50/1535 60.50/1535
Inner Drum Dimensions
Diameter
(inches/mm)
20.87/530 24.40/620 24.40/620 29.53/750 29.53/750 29.53/750
Drum Volume
(gal/L)
19.8/75 27.7/105 35.7/135 39.59/150 52.8/200 61.6/230
Door Opening
(inches/mm)
Weight (lb/kg)
Net 298/135 375/170 419/190 673/305 717/325 761/345
Gross 320/145 408/185 441/200 705/320 750/340 794/360
Electrical Requirements
Supply Voltage
(60 Hz)
208–240 V 1-phase
Power Supply –
Deviations
+ 10%, with max 1% of the frequency
Fuse/Breaker Type Slow (curve D)
GFCI** Class B
Current (Steady
State)
4.8 A 7.5 A 8.1 A 12.5 A 13.0 A 13.2 A
Supply Protection
Device
10 A 10 A 15 A 15 A 15 A 15 A
Washing Functions
Washing 50 RPM 46 RPM 46 RPM 42 RPM 42 RPM 42 RPM
High Extaction 820 RPM 760 RPM 760 RPM 690 RPM 690 RPM 690 RPM
G-Factor 200 200 200 200 200 200
Anchoring
Max. Static Load
on Floor (lb/kg)
427/194 495/225 607/275 899/408 1012/459 1102/499
Max. Dynamic Load
on Floor (lb/kg)
359 + 540/
163 + 245
427 + 899/
194 + 408
495 + 1147/
225 + 520
764 + 1259/
347 + 571
832 + 1686/
377 + 765
877 + 1978/
398 + 897
Frequency of
Dynamic Load
13.7 Hz
12.7 Hz 12.7 Hz 11.5 Hz 11.5 Hz 11.5 Hz
Noise
Equivalent Noise
Level (dB[A])
49 dB(A)
(Wash)
53 dB(A)
(High Spin)
49 dB(A)
(Wash)
53 dB(A)
(High Spin)
50 dB(A)
(Wash)
65 dB(A)
(High Spin)
50 dB(A)
(Wash)
65 dB(A)
(High Spin)
50 dB(A) (Wash)
65 dB(A) (High Spin)
50 dB(A) (Wash)
65 dB(A) (High Spin)
