3-69
8. Remove the two support rods.
9. Reinstall the final two bolts where the
support rods were located.
10. Tighten all the bolt securely.
6. Make sure to reinstall the wire bracket on
the bottom bolt with the washer between the
bracket and the bearing house.
7. Tighten the bolts in an opposing order.
Tighten the bolts until there is no gap
between the bearing house and the support.
Wire
Bracket
To Next Page
