GENERAL INFORMATION
00-00–8
• When there are no specific indications, the standard points and dimensions are symmetrical in regard to the
center of the vehicle.
Example
1,128
{44.41}
A
B
C
H
D
I
E
F
G
1,398
{55.04}
1,406
{55.35}
{42.01}
1,067
799
{31.46}
1,263
{49.72}
1,048
{41.26}
{33.50}
A
F
G
B
H
I
C
D
E,E'
Fr
Fr Fr
FrFr
Fr
Fr
Fr
Fr
Front pillar inner designation
Front pillar inner designation
Front floor pan designation
Adjuster installation hole
Trim installation hole
Harness installation hole
Chaker bracket installation hole
Chaker bracket installation hole
A
B
C
D
E
F
G
H
I
φ 16 {0.62}
φ 18 {0.71}
φ 16 {0.62}
Harness installation hole
Point
symbol
Designation
Hole diameter
or bolt or nut
size mm {in}
Point
symbol
Designation
Hole diameter
or bolt or nut
size mm {in}
Shows bolt size
Shows hole diameter
Shows
slot
851
φ 16 {0.62}
M14 {0.55}
φ 31 {1.22}
φ 17 {0.67}
17 × 29.5
{0.66×1.16}
φ 12 {0.47}
ROOM STRAIGHT-LINE DIMENSIONS (1)
Shows vehicle section
Shows dimension location
Shows outline drawing
Shows point
symbol
Shows point indication
Without apostrophe:RH
With apostrophe:LH
Shows details of the standard
point location
Shows position and shape of the points
Shows dimension
No indication are shown
within the outline drawing.
When there are no specific indications, all of
units are in millimeters (mm).
mm {in}
am3uub0000007
