Mazda 6 2009 - Rear Body Straight-Line Dimensions (1) [Dimensions]

BODY STRUCTURE [DIMENSIONS]
09-80D–13
09-80D
End Of Sie
BM: REAR BODY
REAR BODY STRAIGHT-LINE DIMENSIONS (1) [DIMENSIONS]
id098010746300
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
A
Crossmember No.3 datum
hole
φ6 {0.2}
B C-pillar trim installation hole φ8.6 {0.34}
C C-pillar trim installation hole φ8.6 {0.34}
D
Trunk lid striker installation
hole
φ7 {0.3}
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
A'
A
B'
C'
D'
E'
H'
F'
G'
I'
B
C
D
E
H
F
G
I
1,066 {41.97}
1,397 {55.00}
1,131 {44.53}
1,092 {42.99}
1,254 {49.37}
1,203 {47.36}
1,102 {43.39}
1,123 {44.21}
1,230 {48.43}
RH:675 {26.57}, LH:666 {26.22}
RH:770 {30.31}
LH:760 {29.92}
RH:819 {32.23}
LH:829 {32.64}
1,416 {55.75}
990 {38.98}
911 {35.87}
253 {9.96}
464 {18.27}
914 {35.98}
680 {26.77}
293 {11.54}
343 {13.50}
266 {10.47}
am6xub0000006
