BODY STRUCTURE [WATER-PROOF AND RUST PREVENTIVE]
09-80C–7
09-80C
DUMPING SHEET REPLACEMENT [WATER-PROOF AND RUST PREVENTIVE]
id098009745700
• After repairing the body, attach the dumping sheet to the location shown in the figure for noise insulation.
End Of Sie
LH RH
am6xub0000006
3442-1U-09G(09-80C).fm 7 ページ ２００９年７月２２日　水曜日　午前１１時４６分
