Mazda 6 2009 - Front Body Straight-Line Dimensions (1) [Dimensions]

BODY STRUCTURE [DIMENSIONS]
09-80D–6
FRONT BODY STRAIGHT-LINE DIMENSIONS (1) [DIMENSIONS]
id098010740600
.
A'
A
B'
C'
D'
E'
F'
G'
H'
I'
J'
B
C
D
E
H
J
I
F
G
RH:1,244 {48.98}
LH:1,243 {48.94}
RH:1,002 {39.45}
LH:1,006 {39.61}
RH:1,021 {40.20}
LH:947 {37.28}
RH:330 {12.99}
LH:453 {17.83}
RH:451 {17.76}
LH:446 {17.56}
RH:213 {8.39}
LH:89 {3.50}
770
{30.31}
363
{14.29}
967
{38.07}
902
{35.51}
798
{31.42}
216 {8.50}
1,110
{43.70}
1,536
{60.47}
1,592
{62.68}
1,462
{57.56}
1,263
{49.72}
1,218
{47.95}
1,096
{43.15}
1,317
{51.85}
1,051
{41.38}
mm {in}
am6xub0000000
A B C D E
F G H I,J
am6xub0000000
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
A Roof seamless location -
B Front pillar projection location -
C
Shroud side member datum
hole
φ7 {0.3}
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
