Mazda 6 2009 - Shroud Side Member Removal [Panel Replacement]; Symbol Mark; Removal Procedure

BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–7
09-80B
SHROUD SIDE MEMBER REMOVAL [PANEL REPLACEMENT]
id098008919000
Symbol Mark
Removal Procedure
1. Drill the 6 locations indicated shown in the figure.
2. Remove the front fender bracket.
SYMBOL MARK
MEANING
SPOT WELDING
am6zzb0000001
FRONT FENDER BRACKET
6
am6xub0000001
