BODY STRUCTURE [PANEL REPLACEMENT]
09-80B–5
09-80B
SHROUD SIDE PANEL REMOVAL [PANEL REPLACEMENT]
id098008602700
Symbol Mark
Removal Procedure
1. Drill the 2 locations indicated shown in the figure.
2. Remove the shroud side panel.
End Of Sie
SYMBOL MARK
MEANING
SPOT WELDING
am6zzb0000001
2
SHROUD SIDE PANEL
am6zzb0000015
