Mazda 6 2009 - Front Body Straight-Line Dimensions (2) [Dimensions]

BODY STRUCTURE [DIMENSIONS]
09-80D–7
09-80D
End Of Sie
FRONT BODY STRAIGHT-LINE DIMENSIONS (2) [DIMENSIONS]
id098010740700
.
D Hood hinge installation hole φ8 {0.3}
E
LH:Fuse box installation hole
RH:Subtank installation hole
φ7 {0.3}
F
Front fender panel installation
hole
φ7 {0.3}
G
LH:Engine mounting bracket
No.4 installation hole
RH:Engine mounting bracket
No.3 installation hole
φ7 {0.3}
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
H Front side frame datum hole
LH:φ14 {0.55}
RH:φ20 {0.79}
I
Front bumper reinforcement
installation hole
φ10 {0.39}
J Shroud panel installation hole φ9.1 {0.36}
Point
symbol
Designation
Hole diameter
or bolt or nut
size (mm {in})
C
D
A'
A
B'
C'
D'
E'
B
E
1,336 {52.60}
1,092 {42.99}
1,016 {40.00}
1,062 {41.81}
1,070 {42.13}
1,010 {39.76}
350 {13.78}
719 {28.31}
992 {39.06}
933 {36.73}
920 {36.22}
203 {7.99}
mm {in}
am6xub0000000
A B C D,E
am6xub0000000
